5T Hand Pallet Truck
PRODUCT PARAMETERS
High-Performance 5T Hand Pallet Truck for Industrial Use
The 5T Heavy Duty Hand Pallet Truck by KYdisplay is built to handle heavy loads with precision and ease. Designed with a durable steel frame, it is perfect for warehouses, distribution centers, and industrial settings where material handling is crucial. This manual pallet jack allows operators to lift and move up to 5 tons of weight effortlessly, saving time and improving workflow efficiency.The heavy-duty pallet jack features sturdy wheels that ensure smooth movement across various surfaces, even in high-traffic areas. Ideal for material transport within confined spaces, this reliable tool is engineered to enhance operational productivity and safety. With its simple manual operation, the pallet truck requires minimal maintenance, ensuring long-term performance.
Durable Manual Pallet Jack – Built for Tough Industrial Environments
Our 5T Heavy Duty Hand Pallet Truck is designed to withstand the rigors of industrial environments. The strong steel frame, durable wheels, and reliable hydraulic pump system make this manual pallet jack a must-have for any business requiring efficient material handling solutions. Whether moving pallets of heavy goods or managing logistics in a busy warehouse, this pallet truck will deliver exceptional performance.At KYdisplay, we prioritize quality and reliability in every product we offer. This manual pallet truck is designed for maximum load capacity, ensuring that it meets the demands of even the most challenging environments. The 5 Ton Pallet Truck is ideal for industries such as logistics, manufacturing, and distribution, providing efficient and safe lifting for workers. Explore more Hand Pallet Truck on Pinterest.
Features
- High reliability and long service life of 5 years.
- 40mm integrated hydraulic unit and 6mm steel plate thickness
- The lifting system equipped with overloading protection valve to ensure safe operation.
- The structural design guarantees the convenience of assembling and disassembling.
- Light-weight fork frame, made from high rigidity steel plate.
Technical Parameter
| Model | BF-S-HD5 | |||
|---|---|---|---|---|
| Load Capacity (Q) | kg | 5000 | ||
| Width Overall Forks(K) | mm | 550/685 | ||
| Fork Length (l) | mm | 1150/1220/1500/1800/2000 | ||
| Overall Length(l1) | mm | 1600/1670/1950/2250/2450 | ||
| Handle Height (h2) | mm | 1250 | ||
| Lower Fork Height (h) | mm | 85 | ||
| Overall Lifting Height (h1) | mm | 115 | ||
| Min.Ground Clearance(m) | mm | 30 | ||
| Fork Width (e) | mm | 176 | ||
| Fork Thickness (s) | mm | 60 | ||
| Fork wheel | mm | 85*80 | ||
| Steering Wheel | mm | 200*50 | ||
| Service Weight | Kg | 101-110 | ||
